Fiber Compact Hubs, 32 Ports (CFIT-Flex FCH 32)

Fiber Compact Hubs, 32 Ports (CFIT-Flex FCH 32)

Environmentally-protected enclosure designed for maximum flexibility at MDU fiber distribution locations

Charles’ Flex Compact Hub (FCH) Enclosures were designed around the principal of “flexibility.” These versatile enclosures may be wall or pole mounted and configured for low density Multi-Dwelling Unit (MDU) fiber distribution applications of up to 32 subscribers. With removable feed and drop cable port plates, swing-out bulkhead and hinged tray basket, FCH are technician-friendly and especially efficient at providing rapid FTTX deployment in a variety of multi-subscriber environments.

The FCH offering is a series of non-metallic hub enclosures constructed of lightweight, rugged polycarbonate providing long-life environmental protection. A fiber bulkhead provides technician-friendly access to feed and drop cables without disturbing existing subscriber connections. Internal cable management and bend radius controls maximize cable protection. Simple to install and secure, the FCH is truly a flexible enclosure designed to ensure lower total cost of ownership in all distribution network deployments.

Features and Benefits

Flexibility
Removable cable entry port plates (left and right) each feature a 1” entry grommet to maximize cable entrance/exit

Swing-out fiber bulkhead with 36 SC/APC fiber adapters (4 feed / 32 distribution)
Economic
216-tool lockable door with a padlock hasp forenhanced security
Installation Mounting
Molded-in wall/pole mount brackets for boltingto wood, masonry, and drywall
Technician Friendly Features
Fiber bulkhead provides easy access to feed and drop cable adapters as well as bend radius control and strain relief guides

Efficient internal cable management and routing with multiple tie-down locations
Material Specification
Robust lightweight polycarbonate constructionfor indoor/outdoor use
Environmental
Removable cable entry port plates each feature a 1” entry grommet to maintaining the enclosure’s environmental protection integrity
Industry Certifications
Designed to meet GR-950, GR-2898, NEMA 4, IP66

Product Details

Ordering Information

Please see “Ordering Information” section of the CFIT-Flex Compact-Hub Enclosure (32) Datasheet for configuration details, or CONTACT CHARLES for sales support.
